DEUTZ-FAHR has upgraded its 4E Series, adding a PowerShuttle to this open station tractor range. This has made the 4E Series more comfortable during field work, but also during road transfers and on-farm work, thanks to the SenseClutch, ComfortClutch and Stop&Go functions, as well as the electrohydraulic PTO actuation.
With power outputs from 66 HP/48,9 kW to 102 HP/75 kW, the four new models offer modern technology and comfort at entry-level prices. Boasting 2000 bar common rail fuel injection, exhaust gas recirculation, a DOC catalytic converter, a compact cooling pack, a viscostatic fan and a PowerCore air filter, the turbocharged and intercooled FARMotion 35 engines combine power delivery with fuel efficiency. Both the 4070E and 4080E are equipped with a DPF filter without the need of using Ad-Blue, while the two higher output models – the 4090E and 4100E – feature an exhaust aftertreatment system using both a DPF filter and SCR technology. Ready for the future, the FARMotion engine can run with alternative fuels, being officially certified to run with HVO (Hydrotreated Vegetable Oil), ready to tackle the challenges of the agriculture of tomorrow.
Two transmissions
The new 4E models with PowerShuttle are available with a choice of two transmission versions: with 15+15 speeds or 30+30 speeds with 2-Step Powershift. Both transmissions offer a maximum road speed of 40 km/h attainable at economy engine speed. When fitted with the largest tyre size possible, these tractors can drive at 40 km/h at an engine speed of just 1800 rpm, which is not only reducing fuel consumption but also significantly abating noise emissions. Being a smart PowerShuttle, the new 4E offers a set of additional features which are so far, as one single package, not available on the market. Starting with the SenseClutch feature, which allows to adjust the smoothness of the direction change in 5 steps – for maximum turf protection or faster loading cycles. The ComfortClutch function adds a push button to the gear lever, allowing shifting without the need of pressing the clutch pedal. And finally the Stop&Go feature, which is ideal during front loader application or round bailing, as, when activated, the driver has the possibility to stop and restart the tractor while solely using the brake pedal.
External capacity
Thanks to its high configurability the 4E Series offers perfect solutions for any kind of applications. The optional 56 l/min pump delivers oil to up to three mechanically operated, double acting rear distributors. The lift has a load capacity of up to 3500 kg. The EasyLift system makes the rear lift significantly simpler to use. The mechanically controlled lift can be raised or lowered by simply pressing a button. Three PTO configurations are available: the rich base equipment with its two speeds of 540/540E can be further expanded by adding either the 1000 speed option or the Groundspeed PTO. For maximum comfort, the PTO clutch is actuated electro-hydraulically through a push button.
The controls have been strategically and logically organised in consideration of frequency of use, and are clearly identified using the brand’s tried-and-tested colour-coded scheme. The analogue-digital display on the dashboard provides the operator with clear, immediately legible information on the operating status and functions of the tractor. The mat insulating material further improves comfort by minimising the noise, vibration and heat reaching the operator from the engine. To make operation in poor lighting conditions easier, all models can be fitted with up to 5 optional work lights. A choice of two integrated factory-fitted front loader options are also available (Light kit or Ready kit) to allow for quick and simple attachment of the front loader.
